| Part No. | Pattern | Tire Size | Ply Rating | Load Index Speed Rating | Overall Diameter (inch) | Section Width (inch) | Rim Size (inch) | Inflaed Pressure (psi) | Max. Load (Ibs) | Tread Depth (mm) |
| V23001 | AR30 | 27×9.00R14 | 6 | 60L | 27.2 | 8.8 | 14×7.0 | 22 | 550 | 18 |
| V23002 | AR30 | 27×11.00R14 | 6 | 66L | 27.2 | 10.8 | 14×9.0 | 22 | 660 | 18 |
| V23003 | AR30 | 30×10.00R14 | 8 | 70M | 30.3 | 10.2 | 14×8.0 | 30 | 740 | 18.5 |
| V23004 | AR30 | 30×10.00R15 | 8 | 69M | 30.3 | 10.2 | 15×8.0 | 30 | 715 | 18.5 |
